Legendary Analog “Wasp Deluxe” Multi-Mode Filter Module for Eurorack
Product Features
  • Authentic reproduction of the original “Wasp Deluxe” filter from the 70s

  • Pure analog signal path based on authentic VCF design

  • Multi-mode VCF with Low, High and Band Pass modes

  • Eurorack specs: 8 HP, 30 mA +12 V, 10 mA -12 V

WASP VCF
WASP VCF

Put away that bug spray because the Behringer WASP VCF is one bug you don’t want to get rid of. In fact, we’re pretty sure it’s one you’re definitely going to welcome with open arms!

Faithful to the Original
Faithful to the Original

The Behringer WASP VCF is an authentic reproduction of the original “Wasp Deluxe” filter from the ‘70s. In fact, we’ve released the full-sized WASP DELUXE a few years back, but this time, we wanted to give you the same capabilities in a compact and easy to install module.

Classic Analog Goodness!
Classic Analog Goodness!

Featuring a pure analog signal path, the WASP VCF includes inputs for audio, CV1 and CV2 with respective Level, Frequency and Attenuation controls.

Mix it Up!
Mix it Up!

The WASP VCF also includes a separate band pass output with a corresponding Resonance control to emphasize specific frequencies, as well as a mixed low and high pass output with its mix control so you can blend both the Low Pass and High Pass together.

Eurorack Ready
Eurorack Ready

The WASP VCF is designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and mount the module using the included screws. This allows for the WASP VCF to be mixed with other synth modules for a truly unique set up.

An Amazing Value
An Amazing Value

Get another sweet addition to your setup plus all the classic tones it comes with by getting a Behringer WASP VCF today!

Specification
Inputs
CV 1

3.5 mm TS jack, -5 V to + 5 V range, impedance 50 kΩ

CV 2

3.5 mm TS jack, -5 V to + 5 V range, impedance 50 kΩ

Audio

3.5 mm TS jack, 5 V peak to peak, impedance 50 kΩ

Outputs
BP

3.5 mm TS jack, DC coupled, impedance 1 kΩ

LP/HP

3.5 mm TS jack, DC coupled, impedance 1 kΩ

Controls
Audio Level
Frequency
CV 2 Amount
Resonance
LP/HP mix
Select </Freq
Power Requirements
30 mA (+12 V) / 10 mA (-12 V)
Physical
Standard Operating Temperature

5° C to 40° C (41° F to 104° F)

Dimensions (H x W x D)

129 x 40 x 39 mm (5.06 x 1.59 x 1.55")

Eurorack

8 HP

Weight

70 g (2.47 oz)
