Build the amplifier around the speaker system.
A full-range pair today. Separate low- and high-frequency cabinets tomorrow. The NX1000 lets the same Class-D amplifier serve both plans. Its mode and crossover switches change how it drives the speakers.
Connect sources without adapters
Two combo jacks accept XLR, balanced ¼" TRS or unbalanced ¼" TS connectors. Two locking-style speaker connectors carry the outputs. The input controls set each level, while SIGNAL LEDs show the incoming signal.
Choose the job before the show
Set the MODE SWITCH to MONO, STEREO or BRIDGE. Set the CROSSOVER switch to FULLRANGE, LF or HF. In LF mode it amplifies only the low frequencies, in HF mode only the highs. Both are typically used for bi-amping.
Status you can read from the rack
LIMIT lights when the input exceeds the optimum level and activates the internal limiter. PROTECT lights for an operation error and the affected channel mutes until the error clears. It fits in two rack units. Back-to-front ventilation and a fan that adjusts its speed automatically prevent overheating.
