Bring the turntable back into the system.
The records are back on the shelf, and the turntable works. Yet a turntable delivers a low-level signal, and most audio units only process line level. The PP400 sits between them, so your amplifier, mixer or recorder gets a signal it can use.
Three jobs, one small box
First it equalises the turntable signal to the RIAA specification. Then it amplifies that signal with 35 dB of gain. Finally it sends out a line-level signal.
Pick the output that fits
Connect the turntable to the left and right RCA inputs with a stereo RCA cable. Take the signal out on RCA, or on one ¼" TRS stereo jack. Use one output at a time, not both together. On a mixer, a CD or TAPE input is the place to plug in.
On as soon as it is plugged in
Connecting the included 12 V adapter to the mains switches the PP400 on, and the ON LED lights. It measures about 32 x 103 x 64 mm.
